| Prime Power: | 100KW/125KVA | Standby Power: | 110KW/137.5KVA |
|---|---|---|---|
| Current: | 180A | Frequency: | 50/60HZ |
| Voltage: | 400/230V 220/110V | Color: | Optional |
| Package: | Export Plywood |
We privides a full line of new brand and high quality diesel generator. 100KVA Diesel Generator powered by Weichai, Cummins, Perkins, Deutz, Lovol, Yuchai or Ricardo engine. Weichai powered electric diesel generator set with reliable performance and high technology. Each and every equipement is strictly tested before delivery .
80KW diesel generator Feature
Dual phase system: single or three phase
Dual Voltage output: 200V-240V, 400-440V AC
Rated frequency: 50/60HZ
Power factor: 0.8
Engine(weichai R6105IZLD / WP4D108E200)
Radiator 40°C max, fans are driven by belt ,with safety guard
24V charge alternator
Alternator (STAMFORD UCI274C), single bearing alternator IP23, insulation class H/H
Absorber
Dry type air filter ,fuel filter ,oil filter, coolant filter
Main line circuit breaker
Standard control panel
Two 12V batteries ,rack and cable
Ripple flex exhaust pipe ,exhaust siphone, flange, muffler.User manual
| gensets model(electric dynamo generator) | HX-100GF | ||||||
| Engine | R6105IZLD | ||||||
| Power | 125kva/100kw | ||||||
| Rated Voltage | 400/230V | ||||||
| Rated frequency(HZ) | 50HZ | ||||||
| Rated Speed | 1500rpm | ||||||
| Power Factor(COS) | 0.8(lagging) | ||||||
| Dimensions of open type(mm) (L×W×H) | 2200*800*1400 | ||||||
| Dimensions of sient type(mm) (L×W×H) | 2500*1000*1700 | ||||||
| Gross weight of open type (kg) | 1000 | ||||||
| Gross weight of silent type(kg) | 1200 |
Silent canopy
Controller
Package
Spare parts optional
Installation draft
Cooperator and certificate
